Remote control commands
R&S
®
RTM3000
644User Manual 1335.9090.02 ─ 09
TRIGger:A:CAN:FORMerror <FormError>
Triggers on form errors. A form error occurs when a fixed-form bit field contains one or
more illegal bits.
The command is relevant if TRIGger:A:CAN:TYPE is set to ERRCondition.
Parameters:
<FormError> ON | OFF
*RST: OFF
17.11.5.3 CAN - decode results
In all BUS<b>:CAN... commands, the suffix <b> selects the bus.
BUS<b>:CAN:FCOunt?.................................................................................................. 644
BUS<b>:CAN:FRAMe<n>:TYPE?....................................................................................644
BUS<b>:CAN:FRAMe<n>:STATus?.................................................................................645
BUS<b>:CAN:FRAMe<n>:STARt?...................................................................................645
BUS<b>:CAN:FRAMe<n>:STOP?................................................................................... 646
BUS<b>:CAN:FRAMe<n>:DATA?....................................................................................646
BUS<b>:CAN:FRAMe<n>:ACKState?..............................................................................646
BUS<b>:CAN:FRAMe<n>:ACKValue?............................................................................. 646
BUS<b>:CAN:FRAMe<n>:CSSTate?............................................................................... 647
BUS<b>:CAN:FRAMe<n>:CSValue?................................................................................647
BUS<b>:CAN:FRAMe<n>:DLCState?.............................................................................. 647
BUS<b>:CAN:FRAMe<n>:DLCValue?..............................................................................648
BUS<b>:CAN:FRAMe<n>:IDSTate?.................................................................................648
BUS<b>:CAN:FRAMe<n>:IDTYpe?................................................................................. 648
BUS<b>:CAN:FRAMe<n>:IDValue?.................................................................................648
BUS<b>:CAN:FRAMe<n>:BSEPosition?.......................................................................... 649
BUS<b>:CAN:FRAMe<n>:BCOunt?.................................................................................649
BUS<b>:CAN:FRAMe<n>:BYTE<o>:STATe?....................................................................649
BUS<b>:CAN:FRAMe<n>:BYTE<o>:VALue?....................................................................650
BUS<b>:CAN:FCOunt?
Returns the number of received frames.
Suffix:
<b>
.
1..4
Return values:
<FrameCount> Total number of decoded frames.
Usage: Query only
BUS<b>:CAN:FRAMe<n>:TYPE?
Returns the type of the specified frame.
Serial bus analysis
