Remote control commands
R&S
®
RTP
1301User Manual 1337.9952.02 ─ 12
Suffix Trigger type
17 Qualification is not supported (TV)
18 Qualification is not supported (CDR)
TRIGger<m>:QUALify<n>:STATe...................................................................................1301
TRIGger<m>:QUALify<n>:A[:ENABle]............................................................................1301
TRIGger<m>:QUALify<n>:B[:ENABle]............................................................................1301
TRIGger<m>:QUALify<n>:C[:ENABle]............................................................................1301
TRIGger<m>:QUALify<n>:D[:ENABle]............................................................................1301
TRIGger<m>:QUALify<n>:A:LOGic................................................................................1302
TRIGger<m>:QUALify<n>:B:LOGic................................................................................1302
TRIGger<m>:QUALify<n>:C:LOGic............................................................................... 1302
TRIGger<m>:QUALify<n>:D:LOGic............................................................................... 1302
TRIGger<m>:QUALify<n>:AB:LOGic..............................................................................1303
TRIGger<m>:QUALify<n>:CD:LOGic............................................................................. 1303
TRIGger<m>:QUALify<n>:ABCD:LOGic.........................................................................1303
TRIGger<m>:QUALify<n>:STATe <AddTrigLogi>
Enables the use of the qualification definition for the selected trigger event.
Suffix:
<m>
.
1..3
Only 1 = A-trigger, 2 | 3 = not available. Can be omitted.
<n> 1..18
Defines the trigger type, see Table 22-3.
Parameters:
<AddTrigLogi> ON | OFF
ON
The qualification expression is considered for the trigger event.
OFF
The qualification expression is ignored for the trigger event.
*RST: OFF
Usage: Asynchronous command
TRIGger<m>:QUALify<n>:A[:ENABle] <State>
TRIGger<m>:QUALify<n>:B[:ENABle] <State>
TRIGger<m>:QUALify<n>:C[:ENABle] <State>
TRIGger<m>:QUALify<n>:D[:ENABle] <State>
The command is relevant for qualification, for pattern trigger and for state trigger.
Select the channels to be considered:
●
A[:ENABle]: C1
●
B[:ENABle]: C2
●
C[:ENABle]: C3
Trigger
