Remote control commands
R&S
®
RTP
1356User Manual 1337.9952.02 ─ 12
CURSor<m>:X2ENvelope <EnvelopeCurve2>
If the waveform arithmetics are set to envelope curve (see CHANnel<m>[:
WAVeform<n>]:ARIThmetics on page 1196) and CURSor<m>:TRACking[:
STATe] is set to "ON", this setting defines how the second horizontal cursor is posi-
tioned.
Suffix:
<m>
.
1..*
Selects the cursor set. 4 cursor sets are available.
Parameters:
<EnvelopeCurve2> MIN | MAX
MIN
The horizontal cursor is set to the crossing point of the vertical
cursor with the minimum waveform envelope.
MAX
The horizontal cursor is set to the crossing point of the vertical
cursor with the maximum waveform envelope.
*RST: MAX
Usage: Asynchronous command
CURSor<m>:LABel <ShowLabel>
Shows the cursor labels in the diagram.
Suffix:
<m>
.
1..4
Selects the cursor set.
Parameters:
<ShowLabel> ON | OFF
*RST: ON
Usage: Asynchronous command
CURSor<m>:SIAD <ShwInAllDiags>
Shows the enabled cursor measurements in all active diagrams of the same domain
(time/ spectrum).
Suffix:
<m>
.
1..*
The suffix is irrelevant. All cursor measurements are affected.
Parameters:
<ShowInAllDiagr> ON | OFF
*RST: ON
Usage: Asynchronous command
Cursor measurements
