Remote control commands
R&S
®
RTP
1576User Manual 1337.9952.02 ─ 12
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:I2C:ADDO<m>[:VALue] <SearchName>,<Address>
SEARch:TRIGger:I2C:ADDO<m>[:VALue]? <SearchName>
Defines the address pattern of the indicated ADOR address in the "address OR"
search condition.
Suffix:
<m>
.
1..4
Index of the address in an "address OR" condition (OR slot)
Parameters:
<Address> Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148.
The pattern length is defined with SEARch:TRIGger:I2C:
ADDO<m>:ADRType.
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:I2C:ADDO<m>:RWBit <SearchName>,<RWBit>
SEARch:TRIGger:I2C:ADDO<m>:RWBit? <SearchName>
Defines the R/W bit of the indicated ADOR address in the "address OR" search condi-
tion.
Suffix:
<m>
.
1..4
Index of the address in an "address OR" condition (OR slot)
Parameters:
<RWBit> UNDefined | READ | WRITe | EITHer
UNDefined
Only return value
*RST: EITHer
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:I2C:DPOPerator <SearchName>,<DataPosOperator>
SEARch:TRIGger:I2C:DPOPerator? <SearchName>
Sets the operator for the data position. You can defined an exact position, or a position
range.
Parameters:
<DataPosOperator> ANY | OFF | EQUal | GETHan | INRange | RANGe
ANY = OFF
The position of the required pattern is not relevant.
Protocols
