SEARch:TRIGger:CAN:FDATa[:FDF] <SearchName>,<FDFBit>
SEARch:TRIGger:CAN:FDATa[:FDF]? <SearchName>
Sets the EDL bit (extended data length), which determines whether a frame is CAN or
CAN-FD.
The setting is available in CAN FD option R&S RTP-K9.
Parameters:
<FDFBit> ONE | ZERO | DC
ONE: CAN FD.
ZERO: CAN.
DC: don't care, the format is not relevant.
*RST: DC
Parameters for setting and query:
<SearchName> String with the search name
SEARch:TRIGger:CAN:FDATa:BRS
<SearchName>,<BRSBit>
SEARch:TRIGger:CAN:FDATa:BRS? <SearchName>
Sets the bit rate switching bit for identifier and identifier + data searches.
The setting is available in CAN FD option R&S RTP-K9.
Parameters:
<BRSBit> ONE | ZERO | DC
DC: Don't care
*RST: ONE
Parameters for setting and query:
<SearchName> String with the search name
SEARch:TRIGger:CAN:FDATa:ESI <SearchName>,<ESIBit>
SEARch:TRIGger:CAN:FDATa:ESI? <SearchName>
Sets the error state indicator bit for identifier and identifier + data searches.
The setting is available in CAN FD option R&S RTP-K9.
Parameters:
<ESIBit> ONE | ZERO | DC
*RST: DC
Parameters for setting and query:
<SearchName> String with the search name
22.17.6.5 Search results
The search on decoded CAN data returns the same results as the queries for decode
results.
