Remote control commands
R&S
®
RTP
1776User Manual 1337.9952.02 ─ 12
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<TypeLen> Range: 0 to 65535
Increment: 1
*RST: 0
Usage: Query only
SEARch:RESult:HBTO:FRAMe<m>:STATe?
<SearchName>
Returns the state of the frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<State> OK | ERR_PREAMBLE | ERR_SFD | ERR_LENGTH |
ERR_CRC | UNCorrelated | INComplete
OK
Valid frame.
ERR_PREAMBLE
Erroneous frame due to preamble error.
ERR_SFD
Erroneous frame due to SFD error.
ERR_LENGTH
Erroneous frame due to length / type error.
ERR_CRC
Erroneous frame due to CRC error.
*RST:
OK
Usage: Query only
SEARch:RESult:HBTO:FRAMe<m>:STARt? <SearchName>
Returns the start time of the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Protocols
