Remote control commands
R&S
®
RTP
2000User Manual 1337.9952.02 ─ 12
Parameters:
<RegAddr>
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MDIO:ST <SearchName>,<StartCode>
SEARch:TRIGger:MDIO:ST? <SearchName>
Allows to select the start of frame code of the frame pattern; available only in search
criteria type "Data".
Parameters:
<StartCode> ST00 | ST01 | ST0X
ST00
Clause 45
ST01
Clause 22
ST0X
Any permissible start pattern
*RST: ST0X
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MDIO:TYPE <SearchName>,<Type>
SEARch:TRIGger:MDIO:TYPE? <SearchName>
Selects the event type to search for.
Parameters:
<Type> STARt | STOP | DATA
STARt
Searches for the start of frame (SOF).
STARt
Searches for the end of frame (EOF).
DATA
Allows to specify a payload data pattern (both in Clause 22 or
Clause 45) or an address pattern (in Clause 45, only) to search
for.
*RST: STARt
Parameters for setting and query:
<SearchName>
