Remote control commands
R&S
®
RTP
2077User Manual 1337.9952.02 ─ 12
Parameters:
<IndexMax> Specifies the end value for the index range within the field.
The index range, increment and *RST values depend on the
field type.
Parameters for setting and query:
<SearchName> String with the name of the search.
22.17.20.6 Search results
In all SEARch:RESult:USBThree:FRAMe<m> commands, the suffix <m> selects the
frame number in the list of search results.
SEARch:RESult:USBThree:FRAMe<m>:TYPE?............................................................. 2077
SEARch:RESult:USBThree:FRAMe<m>:INFO?.............................................................. 2077
SEARch:RESult:USBThree:FCOunt?.............................................................................2078
SEARch:RESult:USBThree:FRAMe<m>:STATe?.............................................................2078
SEARch:RESult:USBThree:FRAMe<m>:STARt?.............................................................2078
SEARch:RESult:USBThree:FRAMe<m>:STOP?............................................................. 2079
SEARch:RESult:USBThree:FRAMe<m>:FLD<n>:TYPE?.................................................2079
SEARch:RESult:USBThree:FRAMe<m>:FLD<n>:STATus?.............................................. 2079
SEARch:RESult:USBThree:FRAMe<m>:FLD<n>:STARt?................................................ 2080
SEARch:RESult:USBThree:FRAMe<m>:FLD<n>:STOP?.................................................2080
SEARch:RESult:USBThree:FRAMe<m>:FLD<n>:VAL?................................................... 2081
SEARch:RESult:USBThree:FRAMe<m>:FLD<n>:FVAL?................................................. 2081
SEARch:RESult:USBThree:FRAMe<m>:TYPE? <SearchName>
Returns the frame type for the selected frame number within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<FrameType> TSEQ | TS1T | TS2T | SLF | U2IT | VDT | PCAP | PCNF |
PCNR | LDM | ACK | NRDY | ERDY | STATus | STALl | FWAKe |
LTM | BIAM | HRR | SSPD | PING | PNGR | DPH | DPP | DPPA |
ITP | LC | SKIP | BRST | BDAT | BERC | BCNT | IDLE | UHP |
ULMP | UTP | UDVN | UDEF | ERRor
For a description of the frame types, see "Frame types"
on page 830.
Usage: Query only
SEARch:RESult:USBThree:FRAMe<m>:INFO? <SearchName>
Returns specific frame information details of the selected frame in the search result.
This information is also shown in the "Info" column of the decode results table.
Protocols
