Remote control commands
R&S
®
RTP
2162User Manual 1337.9952.02 ─ 12
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:PCIE:TLP:TYPE <SearchName>,<Type>
SEARch:TRIGger:PCIE:TLP:TYPE? <SearchName>
Sets the transaction type to be searched for in the transaction layer type.
Parameters:
<Type> ANY | MEM | IO | CFG | MSG | CPL | FETCH | SWAP | CAS
*RST: ANY
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:PCIE:TYPE <SearchName>,<Type>
SEARch:TRIGger:PCIE:TYPE? <SearchName>
Parameters:
<Type> TLP | DLLP | ORD | ERR
*RST: TLP
Parameters for setting and query:
<SearchName>
22.17.23.7 Search results
In all SEARch:RESult:PCIE:PACKet<m> commands, the suffix <m> selects the
frame number in the list of search results.
In search result commands, you have to specify the <SearchName> parameter. It is a
string parameter that contains the search definition name.
For a description of the returned values, see the corresponding commands in Chap-
ter 22.17.23.5, "Decode results", on page 2140.
SEARch:RESult:PCIE:PACKet<m>:ADDR?.................................................................... 2163
SEARch:RESult:PCIE:PACKet<m>:CPID?..................................................................... 2163
SEARch:RESult:PCIE:PACKet<m>:CPS?.......................................................................2163
SEARch:RESult:PCIE:PACKet<m>:DATA?.....................................................................2163
SEARch:RESult:PCIE:PACKet<m>:DFC?.......................................................................2164
SEARch:RESult:PCIE:PACKet<m>:FCOunt?..................................................................2164
SEARch:RESult:PCIE:PACKet<m>:FLD<n>:FVAL?.........................................................2164
SEARch:RESult:PCIE:PACKet<m>:FLD<n>:STATus?..................................................... 2165
SEARch:RESult:PCIE:PACKet<m>:FLD<n>:TYPE?........................................................ 2165
SEARch:RESult:PCIE:PACKet<m>:FLD<n>:VAL?...........................................................2165
SEARch:RESult:PCIE:PACKet<m>:HFC?.......................................................................2165
SEARch:RESult:PCIE:PACKet<m>:LEN?.......................................................................2166
SEARch:RESult:PCIE:PACKet<m>:RQID?..................................................................... 2166
SEARch:RESult:PCIE:PACKet<m>:SEQN?.................................................................... 2166
SEARch:RESult:PCIE:PACKet<m>:STARt?....................................................................2167
