Remote control commands
R&S
®
RTP
2209User Manual 1337.9952.02 ─ 12
CHAN1 = CHANnel1, CHAN2 = CHANnel2, CHAN3 = CHAN-
nel3, CHAN4 = CHANnel4
Input channels
EXTernanalog
External analog signal connected to the External Trigger Input.
For this source, only the analog edge trigger is available.
LINE
The instrument generates the trigger from the AC power input
and synchronizes the signal to the AC power frequency.
SBUS
Serial bus
D0...D15
Digital channels (option R&S RTP-B1)
See also: Chapter 22.18.4, "Trigger settings for digital signals
and parallel buses", on page 2208
LOGIc
Logic combination of digital channels, used as trigger source
(option R&S RTP-B1)
MSOB1 | MSOB2 | MSOB3 | MSOB4
Parallel bus (option R&S RTP-B1)
Z1V1 | Z1V2 | Z1V3 | Z1V4 | Z1I1 | Z1I2 | Z1I3 | Z1I4 | Z2V1 |
Z2V2 | Z2V3 | Z2V4 | Z2I1 | Z2I2 | Z2I3 | Z2I4
Input channels of R&S RT-ZVCmulti-channel power probe. Only
available in the A-trigger with trigger type EDGE.
DIFF1 | DIFF2 | COMMON1 | COMMON2
Differential signals
*RST:
CHAN1
Usage: Asynchronous command
TRIGger<m>:PARallel:TYPE <Type>
Selects the trigger type to trigger on digital channels and parallel buses.
To trigger on analog channels or the external trigger input, use TRIGger<m>:TYPE.
Parameters:
<Type> EDGE | WIDTh | TIMeout | SETHold | DATatoclock | STATe |
PATTern | SERPattern |
SETHold = DATatoclock, setup & hold trigger
SERPattern = serial pattern trigger
*RST: EDGE
Usage: Asynchronous command
Mixed signal option (MSO, R&S RTP-B1)
