TRIGger<m>:PARallel:SETHold:CSOurce[:VALue] <ClockSource>
TRIGger<m>:PARallel:STATe:CSOurce:VALue <ClockSource>
TRIGger<m>:PARallel:SPATtern:CSOurce[:VALue] <ClockSource>
Selects the digital channel of the clock signal.
Parameters:
<ClockSource> D0 | D1 | D2 | D3 | D4 | D5 | D6 | D7 | D8 | D9 | D10 | D11 | D12 |
D13 | D14 | D15
*RST: D0
Usage: Asynchronous command
TRIGger<m>:PARallel:EDGE:EXPRession[:DEFine]
<LogicalExpr>
TRIGger<m>:PARallel:WIDTh:EXPRession[:DEFine] <LogicalExpr>
TRIGger<m>:PARallel:TIMeout:EXPRession[:DEFine] <LogicalExpr>
TRIGger<m>:PARallel:STATe:EXPRession[:DEFine] <LogicalExpr>
TRIGger<m>:PARallel:PATTern:EXPRession[:DEFine] <LogicalExpr>
TRIGger<m>:PARallel:SPATtern:EXPRession[:DEFine] <LogicalExpr>
Defines a logical combination of several digital channels as trigger condition if
TRIGger<m>:SOURce[:SELect] is set to LOGIC.
Parameters:
<LogicalExpr> String with logical expression
Example:
TRIGger:PARallel:EDGE:EXPRession 'D1 and D2'
Usage: Asynchronous command
22.18.4.2 Edge trigger
See also:
●
TRIGger<m>:PARallel:EDGE:EXPRession[:DEFine] on page 2210
TRIGger<m>:PARallel:EDGE:SLOPe.............................................................................2210
TRIGger<m>:PARallel:EDGE:SLOPe <Slope>
Defines the edge - the state transition - of the signal to trigger on a single digital chan-
nel (a logic bit), or a logical combination of digital channels.
Parameters:
<Slope> POSitive | NEGative | EITHer
*RST: POSitive
Usage: Asynchronous command
Mixed signal option (MSO, R&S RTP-B1)
