Remote control commands
R&S
®
RTP
2234User Manual 1337.9952.02 ─ 12
PGENerator:FILE:OPEN
Loads the specified pattern file to the instrument.
Usage: Event
Asynchronous command
PGENerator:FILE[:NAME] <FilePath>
Specifies a file path to open a pattern generator file.
Parameters:
<FilePath> String with the name of the file.
PGENerator:HLEVel <HighLevel>
Sets the high level of the pattern generator signal.
Parameters:
<HighLevel> Range: 1.2 to 5
Increment: 0.1
*RST: 1.2
Default unit: V
PGENerator:PRESet
Sets the default pattern generator settings.
Usage:
Event
PGENerator:RUNMode <RunMode>
Sets the duration for which the signal of the pattern generator will be output after the
trigger event.
Parameters:
<RunMode> SINGle | CONTinuous
*RST: CONTinuous
PGENerator:RUNSingle
Executes a single period of the pattern generator, for PGENerator:RUNMode SINGle.
Usage:
Event
Waveform generator (option R&S RTP-B6)
