Chapter 12: Final Recording Medium Setup, Rev. 1.5
secondaryHardenedFormat
The ‘secondaryHardenedFormat’ line is used to indicate the manufacturer of the secondary FRM
in use. If a fixed FRM capsule is used in dual FRM mode with a Float-free SFRM capsule, the
fixed FRM capsule is always
set as the primary FRM. If the VDR is operating in a single FRM
configuration, this value is ignored.
secondaryHardenedFormat = 3 Indicates that the JoTron Float-free SFRM Capsule is in
use as the secondary FRM.
secondaryHardenedFormat = 4 Indicates that the Rutter-ACR Float-free SFRM Capsule is
in use as the secondary FRM.
Table 12-3 – ‘secondaryHardenedFormat' indicates the manufacturer of the secondary FRM.
Example 1: Shows an L3 HVR-01/02 Fixed FRM Capsule (or L3 SVR-01/02 Fixed SFRM
Capsule) in single FRM mode. The secondary format will be ignored in this case.
[STORAGE]
hardenedStorage = 1 // 0=disable, 1=enable, 2 = Dual FRM, default is 0
hardenedFormat = 1 // 1=L3 HVR/SVR, 2=PMC, 3=Jotron, 4=Rutter-ACR Float-free, 5=Rutter Fixed
secondaryHardenedFormat = 4 // 1=L3 HVR/SVR, 2=PMC, 3=Jotron, 4=Rutter-ACR Float-free, 5=Rutter Fixed
Example 2: Shows a JoTron Float-free SFRM Capsule in single FRM mode. The secondary
format will be ignored in this case.
[STORAGE]
hardenedStorage = 1 // 0=disable, 1=enable, 2 = Dual FRM, default is 0
hardenedFormat = 3 // 1=L3 HVR/SVR, 2=PMC, 3=Jotron, 4=Rutter-ACR Float-free, 5=Rutter Fixed
secondaryHardenedFormat = 4 // 1=L3 HVR/SVR, 2=PMC, 3=Jotron, 4=Rutter-ACR Float-free, 5=Rutter Fixed
Example 3: Shows a Rutter FRM (RUT-02447) Fixed Capsule as primary with a Rutter-ACR
Float-free SFRM Capsule as secondary operating in dual FRM mode.
[STORAGE]
hardenedStorage = 2 // 0=disable, 1=enable, 2 = Dual FRM, default is 0
hardenedFormat = 5 // 5=L3 HVR/SVR, 2=PMC, 3=Jotron, 4=Rutter-ACR Float-free, 5=Rutter Fixed
secondaryHardenedFormat = 4 // 1=L3 HVR/SVR, 2=PMC, 3=Jotron, 4=Rutter-ACR Float-free, 5=Rutter Fixed
