A6.1.3.7 Output Baud Rate Configuration
The DataAnalog output baud rate can be configured using the DIP Switch SW1 located on the
DataAnalog circuit board. To access these switches:
 Unplug the front panel input connector;
 Unscrew the two screws located on the front panel of the DataAnalog enclosure in order
to remove the panel;
 The DIP Switches are accessible at the front of the circuit board.
See DataAnalog PCB above for further information on the location of the DIP Switch for baud rate
selection.
Output
Baud Rate
SW1
7
SW1
8
4800 OFF OFF
9600 ON OFF
19200 OFF ON
57600 ON ON
Table A6 - 4 - Output Baud Rate
A6.1.3.8 NMEA-0183/IEC 61162 String Identifier Configuration
Should more than one DataAnalog be required, it is necessary to program a unique string
identifier for each. The DataAnalog identifier can be programmed using the DIP Switch located on
the DataAnalog circuit board. To access this switch:
1. Unplug the front panel input connector(s);
2. Unscrew the two screws located on the front panel of the DataAnalog enclosure in order
to remove the panel;
3. Slide the circuit board out of the enclosure.
The DIP Switch for configuring the string identifier is labelled SW1, located as shown above
(DataAnalog PCB above). Table A6 – 5 on the next page gives the switch settings necessary for
programming the DataAnalog String Identifier:
