Chapter 2: Technical Specifications, Rev 1.1
Rutter FRM/SFRM (RUT-02447)
Weight 18 kg
Dimensions Height: 350 mm, Diameter 220 mm
Input Power 24VDC
Memory Type Solid State
Capacity
Minimum of 12 +12 hours recording time: 8 GB: 4 GB (protected) + 4GB
unprotected for incident recording. Additional memory (optional): up to 160
GB for longer recording times or extended number of recording channels. )
2.5 OAU Specifications
Weight 1.4Kg
Dimensions
With front mounting plate: 144 x 144 x 52.3mm
Without front mounting plate: 136.6 x 136.6 x 50mm
Input Power 24VDC
Audible Alarm 55dBA
2.6 Indoor Microphone Assembly Specifications
Weight 0.95Kg
Dimensions Mic: 64 x 92 x 31mm / Box: 80 x 149.1 x 56.5mm
Input Power Phantom Power
2.7 Optional Outdoor Microphone Specifications
Weight 1.17Kg
Dimensions Mic: 64 x 92 x 31mm / Box: 85.1 x 129.9 x 65.7mm
Input Power Phantom Power
VDR-100G3/G3S Installation Manual 08/10/2008
2-4
