Chapter 2: Technical Specifications, Rev 1.1
2.3 DAU Specifications (DAU Cabinet is optional)
Weight 16.8Kg
Dimensions 400 x 600 x 150mm (H x W x D)
Input Power 24VDC from DPU
Output Power 24VDC to remote interfaces (Max 6A)
Audio Input Capacity
8, 12, or 16 Audio inputs
Flexible Microphone and VHF/Line level combinations
Video Input Capacity
Up to 4 video input ports
170MHz pixel rate with 2 mega pixels input resolution, up to 340MHz pixel
rate captured from two consecutive frames with clock inversion (Includes
1600 x 1200 x 75 Hz & 1280 x 1024 x 85 Hz)
24 bit RGB; monochrome
H and V sync input
Data Input Capacity
8 or 16 NMEA 0183/IEC61162 Data Input ports.
Interfaces for converting non-standard signal formats are to be DIN rail
mounted as close to the signal source as practical. The following
interfaces are available for remote mounting:
DataAnalog analog signal interface
DataDiscrete contact signal interface
DataGyro gyrocompass interface
DataSynchro synchro interface
VDR-100G3/G3S Installation Manual 08/10/2008
