2 VDR-100G3/G3S TECHNICAL SPECIFICATIONS
The following tables contain a summary of the technical specifications for the Rutter VDR-100G3
system components:
2.1 Power Consumption
Normal Operating Current (approx.)
0.80 A @220VAC
0480 A @120VAC
Maximum Current Draw (approx.)
1.2 A @220VAC
2.1 A @120VAC
Recommended Ship Main Breaker
10 A @220VAC
10 A @120VAC
2.2 DPU Specifications
Weight 20.2 Kg
Dimensions 457 x 457 x 150mm (H x W x D)
Input Power 85 -264 VAC 50-60Hz
Output Power
24VDC to FRM, Audio, Video, NMEA, Alarm Module, optional Remote
Storage and optional interfaces
Data Ports
Ethernet input from Audio, Video, and NMEA Modules
Ethernet Output to FRM
Ethernet Output / Download PC
RS232 Input/Output for Alarm Module
USB and optional remote storage
Battery Backup Power 2 Hrs @ -15 Deg C for Audio system, Alarm Module, DMM, and FRM
Data Storage Capacity
The internal HDD is 160GB
Current Data = 4.88GB
Internal Secured Data = 20G
Internal Archived Data = 124GB
(NOTE: Some storage reduction due to drive partitioning)
USB memory stick
External Archived data
VDR-100G3/G3S Installation Manual 08/10/2008
2-1
