VDR Installation & Commissioning Checklist, Rev 1.2
2 Set to Work & Commissioning
It is required that the technician implementing this procedure mark the boxes located to the right of the items to indicate
acceptance of the item.
If the item has been completed the technician must mark the YES column in order to indicate compliance with associated
item (non-compliance should be indicated by marking the NO column).
Once all items in each section have been checked, the technician should then initial and date his/her findings directly
below the items.
The ship can be dockside for this procedure.
Please print technician name:
Test Conditions
VDR is powered on.
VHF source is powered on.
Radar(s) is (are) powered on.
Sensors / Data sources are transmitting data.
Ship at sea or engines operational (as required).
2a. Bridge & VHF Audio is configured for recording
YES NO N/A
Detection thresholds have been set for all microphones.
Microphone test is passing successfully for all microphones.
Audio is clear during data playback on all recorded channels.
Both transmit and receive of VHF is being recorded properly.
VHF audio is clear upon playback of data.
Technician Initialed: ______________________ Date: __________
2b. Video sources are configured for recording
Video Channel 1 appears correctly in video test mode.
Video Channel 1 appears correctly during playback.
Video Channel 2 appears correctly in video test mode.
Video Channel 2 appears correctly during playback.
Video Channel 3 appears correctly in video test mode.
VDR Installation Manual 06/10/2008
4
