Appendix 6: External Interface Modules, Rev. 1.1
Channel A1 Channel A2
SW2
1
S5
1
S9
4
S9
3
SW2
1
S5
2
S9
2
S9
1
0-5V
OFF ON ON OFF OFF ON ON OFF
0-10V
OFF OFF ON OFF OFF OFF ON OFF
+/-5V
ON ON ON OFF ON ON ON OFF
+/-10V
ON OFF ON OFF ON OFF ON OFF
4-20mA
OFF ON OFF ON OFF ON OFF ON
+/-5V (HI*)
ON ON OFF OFF ON ON OFF OFF
0-5V (HI*)
OFF ON OFF OFF OFF ON OFF OFF
Channel B1 Channel B2
SW2
2
S4
1
S8
4
S8
3
SW2
2
S4
2
S8
2
S8
1
0-5V
OFF ON ON OFF OFF ON ON OFF
0-10V
OFF OFF ON OFF OFF OFF ON OFF
+/-5V
ON ON ON OFF ON ON ON OFF
+/-10V
ON OFF ON OFF ON OFF ON OFF
4-20mA
OFF ON OFF ON OFF ON OFF ON
+/-5V (HI*)
ON ON OFF OFF ON ON OFF OFF
0-5V (HI*)
OFF ON OFF OFF OFF ON OFF OFF
Channel C1 Channel C2
SW2
3
S3
1
S7
4
S7
3
SW2
3
S3
2
S7
2
S7
1
0-5V
OFF ON ON OFF OFF ON ON OFF
0-10V
OFF OFF ON OFF OFF OFF ON OFF
+/-5V
ON ON ON OFF ON ON ON OFF
+/-10V
ON OFF ON OFF ON OFF ON OFF
4-20mA
OFF ON OFF ON OFF ON OFF ON
+/-5V (HI*)
ON ON OFF OFF ON ON OFF OFF
0-5V (HI*)
OFF ON OFF OFF OFF ON OFF OFF
Channel D1 Channel D2
SW2
4
S2
1
S6
4
S6
3
SW2
4
S2
2
S6
2
S6
1
0-5V
OFF ON ON OFF OFF ON ON OFF
0-10V
OFF OFF ON OFF OFF OFF ON OFF
+/-5V
ON ON ON OFF ON ON ON OFF
+/-10V
ON OFF ON OFF ON OFF ON OFF
4-20mA
OFF ON OFF ON OFF ON OFF ON
+/-5V ( HI*)
ON ON OFF OFF ON ON OFF OFF
0-5V (HI*)
OFF ON OFF OFF OFF ON OFF OFF
Table A6 - 3 - Switch settings and range
* HI represents high impedance settings.
Warning! Incorrect switch settings and exceeding the selected range can damage the
DataAnalog
.
Output Format
DataAnalog:
$ANLXX,[A
1
],[A
2
],[B
1
],[B
2
],[C
1
],[C
2
],[D
1
],[D
2
] *AA
where:
 XX is set between 00 to 63 (see NMEA-0183/IEC 61162 String Identifier Configuration
section below)
 A
1-2
, B
1-2
, C
1-2
, D
1-2
are values between –4096 and +4094 that represent the voltage or
current on the corresponding input channel
 AA is the checksum.
Example: $ANL12,1234,2344,-3456,-4094,1234,2344,-3456,-4094*F5
