Santerno Sinus Penta - List of Parameters P050 to P074 A

SINUS PENTA
PROGRAMMING GUIDE
112/486
13.3. List of Parameters P050 to P074a
Table 27: List of parameters P050 to P074a
Parameter FUNCTION User Level
DEFAULT
VALUE
MODBUS
Address
P050
Type of signal over REF input
ADVANCED
3: 0÷10V
650
P051
Value of REF input producing min. reference (X-axis)
ADVANCED
0.0V
651
P051a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P051)
ADVANCED 100.0% 675
P052
Value of REF input producing max. reference (X-axis)
ADVANCED
10.0V
652
P052a
Percentage of Speed_Max/Trq_Max producing max.
reference (Y-axis related to P052)
ADVANCED 100.0% 676
P053
Offset over REF input
ADVANCED
0V
653
P054
Filtering time over REF input
ADVANCED
5 ms
654
P055
Type of signal over AIN1 input
ADVANCED
2: 4÷20mA
655
P056
Value of AIN1 input producing min. reference (X-axis)
ADVANCED
4.0mA
656
P056a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P056)
ADVANCED 100.0% 677
P057
Value of AIN1 input producing max. reference (X-axis)
ADVANCED
20.0mA
657
P057a
Percentage of Speed_Max/Trq_Max producing max.
reference (Y-axis related to P057)
ADVANCED 100.0% 678
P058
Offset over AIN1 input
ADVANCED
0mA
658
P059
Filtering time over AIN1 input
ADVANCED
5 ms
659
P060
Type of signal over AIN2 input
ADVANCED
2: 4÷20mA
660
P061
Value of AIN2 input producing min. reference (X-axis)
ADVANCED
4.0mA
661
P061a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P061)
ADVANCED 100.0% 679
P062
Value of AIN2 input producing max. reference (X-axis)
ADVANCED
20.0mA
662
P062a
Percentage of Speed_Max/Trq_Max producing max.
reference (Y-axis related to P062)
ADVANCED 100.0% 701
P063
Offset over AIN2 input
ADVANCED
0mA
663
P064
Filtering time over AIN2 input
ADVANCED
5 ms
664
P065
Minimum reference and START disabling threshold
ADVANCED
0
665
P066
START disable delay at P065 threshold
ADVANCED
0s
666
P067
Keypad and terminal board UP/DOWN ramp
ADVANCED
Quadratic
667
P068
Storage of UP/DOWN values at Power Off
ADVANCED
YES
668
P068a
Reset UP/DOWN speed/torque at Stop
ADVANCED
0:[NO]
940
P068b
Reset UP/DOWN PID at Stop
ADVANCED
0:[NO]
941
P068c
Reset UP/DOWN speed/torque at Source Changeover
ADVANCED
0:[NO]
942
P068d
Reset UP/DOWN PID at Source Changeover
ADVANCED
0:[NO]
943
P069
Range of UP/DOWN reference
ADVANCED
1: Unipolar
669
P070
Jog reference (speed/torque)
ADVANCED
0%
670
P071
Value of FIN producing min. reference (X-axis)
ADVANCED
10 kHz
671
P071a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P071)
ADVANCED 100.0% 713
P072
Value of FIN producing max. reference (X-axis)
ADVANCED
100 kHz
672
P072a
Percentage of Speed_Max/Trq_Max producing max.
reference (Y-axis related to P072)
ADVANCED 100.0% 714
P073
Value of ECH producing min. reference (X-axis)
ADVANCED
0 rpm
673
P073a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P073)
ADVANCED 100.0% 702
P074
Value of ECH producing max. reference (X-axis)
ADVANCED
+1500 rpm
674
P074a
Percentage of Speed_Max/Trq_Max producing max.
reference (Y-axis related to P074)
ADVANCED 100.0% 703
