Santerno Sinus Penta - Alarm List

SINUS PENTA
PROGRAMMING GUIDE
452/486
58.3. Alarm List
Table 136: List of the possible alarms
Alarm
Alarm Message
Description
A001 ÷ A032
…
Control board failure
A033
TEXAS VER KO
Incompatible Texas Software Version
A039
FLASH KO
Texas Flash not programmed
A040
User Fault
Alarm caused by the user
A041
PWMA Fault
General hardware fault from IGBT, side A
A042
Illegal XMDI in DGI
Illegal configuration of XMDI in the Digital Inputs menu
A043
False Interrupt
Control board failure
A044
SW OverCurrent
Software overcurrent
A045
Bypass Circuit Fault
Fault of the precharge By–Pass
A046
Bypass Connector Fault
Precharge By–Pass connector fault
A047
UnderVoltage
Dc bus voltage lower than Vdc_min
A048
OverVoltage
Dc bus voltage exceeding Vdc_max
A049
RAM Fault
Control board failure
A050
PWMA0 Fault
Hardware Fault from IGBT converter, side A
A051
PWMA1 Fault
Hardware overcurrent, side A
A052
Illegal XMDI in DGO
Illegal configuration of XMDI in the Digital Outputs menu
A053
PWMA Not ON
Hardware failure, IGBT A power on impossible
A054
Optional Board not in
Failure in detecting preset optional I/O board
A055
PTC Alarm
External PTC tripped
A056
PTC Short Circuit
External PTC in short circuit
A057
Illegal XMDI in MPL
Illegal configuration of XMDI in the Virtual Digital Outputs (MPL) menu
A059
Encoder Fault
Error of motor speed measure
A060
NoCurrent Fault
Current is zero in FOC control
A061
Ser WatchDog
Watchdog tripped in serial link 0 (9-pole D connector)
A062
SR1 WatchDog
Watchdog tripped in serial link 1 (RJ45)
A063
Generic Motorola
Control board failure
A064
Mains Loss
No power is supplied from the mains
A065
AutoTune Fault
Autotune failed
A066
REF < 4mA
REF Current input (4÷20mA) lower than 4mA
A067
AIN1 < 4mA
AIN1 Current input (4÷20mA) lower than 4mA
A068
AIN2 < 4mA
AIN2 Current input (4÷20mA) lower than 4mA
A069
XAIN5 < 4mA
XAIN5 Current input (4÷20mA) lower than 4mA
A070
Fbs WatchDog
Fieldbus Watchdog tripped
A071
1ms Interrupt OverTime
Control board failure
A072
Parm Lost Chk
Parameter download/upload error
A073
Parm Lost COM1
Parameter download/upload error
A074
Drive OverHeated
Drive thermal protection tripped
A075
Motor OverHeated
Motor thermal protection tripped
A076
Speed Alarm
Motor speed too high
A078
MMI Trouble
Control board failure
A079
Encoder not conf.
FOC control but Encoder not properly configured
A080
Tracking Error
Encoder speed tracking error
A081
KeyPad WatchDog
Communication watchdog via keypad
A082
Illegal Encoder Cfg
Functions programmed for MDI6 and MDI7 or
encoder B selected and encoder board not detected.
A083
External Alarm 1
External alarm 1
A084
External Alarm 2
External alarm 2
A085
External Alarm 3
External alarm 3
A086
XAIN5 > 20mA
XAIN5 Current input (4÷20mA or 0÷20mA) greater than 20mA
A087
±15V LOSS
± 15V Loss
A088
ADC Not Tuned
Control board failure
A089
Parm Lost COM2
Parameter download/upload error
A090
Parm Lost COM3
Parameter download/upload error
A091 Braking Resistor Overload
Overvoltage tripped with braking resistor activated due to continuous
operation time exceeding the max. programmed time
