37.3. List of Parameters C149 to C188c and I006
The parameters ranging from C149 to C180 and from C186 to C188c (one for each command function) activate single
functions and set the terminal for each enabling/disabling function.
Parameter C181 enables a safe START mode.
Parameter C182 enables multiple programming (if compatible) to the same terminal. Max. two functions can be
programmed to the same input.
Table 98: List of parameters C149 to C188c and I006
Parameter FUNCTION User Level
MODBUS
Address
Default
Values
I006
Function selection for MDI control
ADVANCED
1393
inactive
C149
START Input
ADVANCED
1149
MDI1
C149a
START Input B
ADVANCED
1297
none
C150
STOP Input
ADVANCED
1150
none
C150a
STOP B Input
ADVANCED
1298
none
C151
REVERSE Input
ADVANCED
1151
none
C151a
REVERSE B Input
ADVANCED
1299
none
C152
ENABLE-SW Input
ADVANCED
1152
none
C153
DISABLE Input
ADVANCED
1153
none
C154
Disable RESET alarms on MDI3
ADVANCED
1154 bit 0
NO
C154a
ENABLE from Terminal Board Only
ADVANCED
1154 bit 1
NO
C155
MULTISPEED 0 Input
ADVANCED
1155
MDI4
C156
MULTISPEED 1 Input
ADVANCED
1156
MDI5
C157
MULTISPEED 2 Input
ADVANCED
1157
none
C158
MULTISPEED 3 Input
ADVANCED
1158
none
C159
CW/CCW Input
ADVANCED
1159
MDI8
C160
DCB Input
ADVANCED
1160
none
C161
UP Input
ADVANCED
1161
none
C162
DOWN Input
ADVANCED
1162
none
C163
RESET UP/DOWN Input
ADVANCED
1163
none
C164
External alarm 1 Input
ADVANCED
1164
none
C164a
External alarm 1 trip delay
ADVANCED
1305
immediate
C165
External alarm 2 Input
ADVANCED
1165
none
C165a
External alarm 2 trip delay
ADVANCED
1306
immediate
C166
External alarm 3 Input
ADVANCED
1166
none
C166a
External alarm 3 trip delay
ADVANCED
1307
immediate
C167
MultiRamp 0 Input
ENGINEERING
1167
none
C168
MultiRamp 1 Input
ENGINEERING
1168
none
C169
JOG Input
ADVANCED
1169
none
C169a
Input for Selection of Speed Regulator
Parameters
ADVANCED 1233 none
C170
SLAVE Input
ADVANCED
1170
none
C171
PID DISABLE Input
ADVANCED
1171
none
C171a
Input for PID control selection
ENGINEERING
1188
none
C172
KEYPAD LOCK Input
ADVANCED
1172
none
C173
MOTOR 2 SEL. Input
ENGINEERING
1173
none
C174
MOTOR 3 SEL. Input
ENGINEERING
1174
none
C175
SPEED VAR. 0 Input
ENGINEERING
1175
none
C176
SPEED VAR. 1 Input
ENGINEERING
1176
none
C177
SPEED VAR. 2 Input
ENGINEERING
1177
none
C178
PID RESET UP/DOWN input
ADVANCED
1178
none
C179
SOURCE SELECTION Input
ADVANCED
1179
MDI6
C179a
COMMAND SELECTION Input
ADVANCED
1238
none
C179b
REFERENCE SELECTION Input
ADVANCED
1239
none
C180
LOC/REM Input
ADVANCED
1180
MDI7
C180a
Type of LOC/REM contact
ADVANCED
1303
pushbutton+storage
C181
Safety Start enable
ADVANCED
1181
inactive
C182
Multiprogramming enable
ENGINEERING
1182
inactive
C183
Max. fluxing time before drive Disable
ADVANCED
1183
disabled
C184
Fluxing at activation only with START closed
ADVANCED
1184
no
