8.6. Outputs Menu
This menu allows checking the status of the digital outputs, the analog outputs and the frequency outputs located in the
terminal board.
M056 Digital Outputs
M056
Range
Bit-controlled measure.
See Table 5
Active
Always active.
Address
1706
Function
Status of digital outputs MDO1÷4 and status of the precharge contactor.
Table 5: Coding of Measure M056
Bit n.
Digital Output
0
MDO1/FOUT
1
MDO2
2
MDO3
3
MDO4
6
Status of the precharge
contactor
M056a Virtual Digital Outputs
M056a
Range
Bit-controlled measure.
See Table 6
Active
Always active.
Address
1675
Function
Status of virtual digital outputs MPL1÷4.
Table 6: Coding of Measure M056a
Bit n.
Digital Output
0
MPL1
1
MPL2
2
MPL3
3
MPL4
M056b Timed Flags
M056b
Range
Bit-controlled measure
See Table 7
Active
Always active.
Address
1741
Function
Status of timed flags TFL1 ÷ 4.
Table 7: Coding of Measure M056b
Bit n.
Timed Flag
0
TFL1
1
TFL2
2
TFL3
3
TFL4
