59. CUSTOM PARAMETERS
In the table below, you can write down settings that are different from the default values.
PAR.-Meaning Default values Modified values PAR.-Meaning Default Values Modified values
P00x Access Level
P001-AcsLev
0: Basic
P003-ModCmode
1:[StandBy+Fluxing]
Product
P263-Lang
1: ENGLISH
P26x Display
P264-ModNav
0: Menu
P264a-ModNavMenu
1: Yes
P264b-ModMenu
0: Standard
P265-FirstPage
3: [Start Up]
P266-kpd_type
1: Active Ref.
P267-umis1_PID
0: Disable
P267a- Custom PID unit of
measures
[%]
P268-Measure n.1 Status
Page
M004
P268y-Scaling
Measure n.1 Status Page
100.00%
P268a-Measure n.2 Status
Page
M000
P268z-Scaling
Measure n.2 Status Page
100.00%
P268b-Measure n.1
Keypad Page
M006
P268c-Measure n.2
Keypad Page
M026
P268d-Measure n.3
Keypad Page
M004
P268e-Measure n.4
Keypad Page
M000
P269-DisabKey1
0: No
P269a-DisabKey2
0: No
P269b-EscKeyFunc
0: No
P00x-P03x Ramps
P009-Tup1
[*]
P010-Tdn1
[*]
P012-Tup2
[*]
P013-Tdn2
[*]
P014-Un.Meas1-2
[*]
P015-Tup3
[*]
P016-Tdn3
[*]
P018-Tup4
[*]
P019-Tdn4
[*]
P020-Un.Meas3-4
[*]
P021a-Rnd.Sel1
1: On
P021b-Rnd.Sel2
1: On
P021c-Rnd.Sel3
1: On
P021d-Rnd.Sel4
1: On
P022-RndStartAcc
[*]
P023-RndStopAcc.
[*]
P024-RndStartDec
[*]
P025-RndStopDec
[*]
P026-T Tup
5.00 s
P027-T Tdn
5.00 s
P028-T Un.Mea
1: 0.1 s
P029-J Tup
1 s
P030-J Tdn
1 s
P031-SpdAccReset
1: Yes
P032-TupFireM
[*]
P033-TdnFireM
[*]
P05x-P07x Reference
P050-REF
3: 0-10V
P051-REFMIN
0.0 V
P051a-REFMIN_%
100%
P052-REFMAX
10.0 V
P052a-REFMAX_%
100%
P053-REFOFFS
0.000 V
P054-TauFilt REF
5 ms
P055-AIN1
2: 4-20mA
P056-AIN1MIN
4.0 mA
P056a-AIN1MIN_%
100%
P057-AIN1MAX
20.0 mA
P057a-AIN1MAX_%
100%
P058-AIN1OFFS
0.000 mA
P059-TauFilt AIN1
5 ms
P060-AIN2
2: 4-20mA
P061-AIN2MIN
4.0 mA
P061a-AIN2MIN_%
100%
P062-AIN2MAX
20.0 mA
P062a-AIN2MAX_%
100%
P063-AIN2OFFS
0.000 mA
P064-TauFilt AIN2
5 ms
P065-SpdDisab
0 rpm
P066-SpdDisabTime
0 s
P067-U/D Ramp
Square
P068-U/D Mem
1: Yes
P068a-U/D1-StopRes
0: No
P068b-U/D2-StopRes
0: No
P068c-U/D1SwSRes
0: No
P068d-U/D2SwSRes
0: No
P069-U/D Range
1: Unipolar
P070-Jog Ref
0 %
P071-PulseMin
10000 Hz
P071a-PulseMin_%
100%
P072-PulseMax
100000 Hz
P072a-PulseMax_%
100%
P073-EncMin
0 rpm
P073a-EncMin_%
100%
P074-EncMax
1500 rpm
P074a-EncMax_%
100%
