22.2.2. ANALOG OUTPUT PROGRAMMING EXAMPLES
This section contains a description of operating examples of the analog outputs obtained with different programming
modes.
Example 1:
Table 37: Programming AO1 (0÷ 10V)
Parameterization of AO1 Analog Output
Parameter
Value
Description
P176
0÷10V
AO1 Analog output
P177
1: Speed
Selected variable for AO1 analog output
P178
–500 rpm
Min. value of AO1 selected variable
P179
+500 rpm
Max. value of AO1 selected variable
P180
0.000 V
AO1 Analog output offset
P181
0 ms
Filter for AO1 analog output
P182
0.0 V
Min. AO1 output value with reference to P178
P183
10.0 V
Max. AO1 output value with reference to P179
Figure 18: Curve (voltage; speed) implemented by AO1 (Example 1)
0
1
2
3
4
5
6
7
8
9
10
-500 -400 -300 -200 -100
0 100 200
300 400 500
( rpm )
( V )
Example 2:
Table 38: Programming AO1 (0 ÷ 10V)
Parameterization of Analog Output AO1
Parameter
Value
Description
P176
ABS 0÷10V
AO1 Analog output
P177
1: Speed
Selected variable for AO1 analog output
P178
0 rpm
Min. value of AO1 selected variable
P179
+500 rpm
Max. value of AO1 selected variable
P180
0.000 V
AO1 Analog output offset
P181
0 ms
Filter for AO1 analog output
P182
0.0 V
Min. AO1 output value with reference to P178
P183
10.0 V
Max. AO1 output value with reference to P179
