Santerno Sinus Penta - Table 62: Test Functions

SINUS PENTA
PROGRAMMING GUIDE
228/486
Variable B selected for MPL1 (2, 3, 4): P352, (P361, P370, P379)
This selects a different digital signal or the analog variable used for Test B (set with P354 / P363 / P372 / P381).
The whole list of the selectable items and their description are stated in Table 48.
If a digital signal is selected, Test B is not performed: therefore, the comparison value for Test B (set with P356 / P365 /
P374 / P383) has no meaning.
NOTE
Parameter P352 cannot be accessed when the digital output operating mode is
1: DIGITAL or 3: ANALOG.
Example: MPL1 P350=1 OR P350=3.
Testing Variable A for MPL1 (2, 3, 4): P353, (P362, P371, P380)
If an analog variable is selected, a logic TEST is performed to obtain a TRUE/FALSE Boolean signal.
Eight different tests are available, that can be performed for selected variable A and its comparing value A:
Table 62: Test functions
GREATER THAN
Selected variable > comparing value
GREATER THAN/EQUAL TO
Selected variable ≥ comparing value
LOWER
Selected variable < comparing value
LOWER THAN/EQUAL TO
Selected variable ≤ comparing value
ABS, GREATER THAN
Absolute value (selected variable) > comparing value
ABS, GREATER THAN/EQUAL TO
Absolute value (selected variable) ≥ comparing value
ABS, LOWER
Absolute value (selected variable) < comparing value
ABS, LOWER THAN/EQUAL TO
Absolute value (selected variable) ≤ comparing value
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2. Example: MPL1 P350>2.
Operation on variable B, digital output MPL1 (2, 3, 4): P354, (P363, P372, P381)
If an analog variable is selected, a logic TEST is performed to obtain a TRUE/FALSE Boolean signal.
Eight different tests are available, that can be performed for selected variable B and its comparing value B (see Table
62).
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2 and < 9. Example: MPL1 2<P350<9.
Reference threshold for P351 ( P360, P369, P378) in MPL1 (2, 3, 4): P355, (P364, P373, P382)
Defines the comparing value of Test A with the first selected variable.
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2. Example: MPL1 P350>2.
Reference threshold for P352 ( P361, P370, P379) in MPL1 (2, 3, 4): P356, (P365, P374, P383)
Defines the comparing value of Test B with the first selected variable.
NOTE
This parameter can be accessed only if the operating mode of the selected digital output
is > 2. Example: MPL1 P350>2.
