Santerno Sinus Penta - List of Parameters P264 to P269 B

SINUS PENTA
PROGRAMMING GUIDE
86/486
11.4. List of Parameters P264 to P269b
Table 20: List of parameters P264 to P269b
Parameter FUNCTION User Level DEFAULT SETTING
MODBUS
Address
P264
Navigation mode
ADVANCED
0 :[BY MENU]
864
P264a
Circular navigation
ADVANCED
1: [YES]
865
P264b
Navigation mode with the MENU key
ADVANCED
0:[STANDARD]
512
P265
Root page
ADVANCED
3: [Start Up]
866
P266
Type of Keypad page in Local Mode
ADVANCED
1:[Ref.Activated]
511
P267
Preset PID units of measure
ENGINEERING
0:[Disable]
867
P267a
Custom PID units of measure
ENGINEERING
[%]
1867
P267b
Preset PID2 units of measure
ENGINEERING
0:[Disable]
861
P267c
Custom PID2 units of measure
ENGINEERING
[%]
1869
P268
Measure n.1 on Root page
ADVANCED
M004 Motor Spd
cannot be accessed
P268y
Scaling of Measure n.1 on Root page
ADVANCED
100.00%
515
P268a
Measure n.2 on Root page
ADVANCED
M000 Speed Ref.
cannot be accessed
P268z
Scaling of Measure n.2 on Root page
ADVANCED
100.00%
516
P268b
Measure n.1 on Keypad page
ADVANCED
M006 Mot.Freq.
cannot be accessed
P268c
Measure n.2 on Keypad page
ADVANCED
M026 Motor Current
cannot be accessed
P268d
Measure n.3 on Keypad page
ADVANCED
M004 Motor Spd
cannot be accessed
P268e
Measure n.4 on Keypad page
ADVANCED
M000 Speed Ref.
cannot be accessed
P269
Disable LOC/REM FWD/REV keys
ENGINEERING
[NO NO]
869
P269b
ESC key to restore previous value
ENGINEERING
[NO]
1051
P264 Navigation Mode
P264 Range
0 ÷ 2
0: By Menu
1: Changed Pars Only
2: Linear
Default
0
0: By Menu
Level
ADVANCED
Address
864
Function
Navigation by menu is factory-set and is activated whenever the Penta drive is
powered on.
Set P264=1:[Changed Pars Only]
to navigate only through the parameters whose
default values have been changed.
In that case, linear navigation becomes active: only the parameters that have been
changed are displayed in sequence. Press the ▲ and ▼
keys to go to a different
parameter. Navigation is slower if only few parameters have been changed.
Set P264=2:[Linear] to display parameters in sequence using the ▲ and ▼ keys.
If
Linear navigation is selected, parameters are no longer divided into menus and
submenus.
NOTE
This parameter cannot be saved. Navigation by menu is restored whenev
er the drive is
powered on.
