24.5. List of Parameters P236 to P260
Table 45: List of parameters P236 to P260
Parameter FUNCTION User Level Default Values
MODBUS
Address
P236
Max. value of PID output
ENGINEERING
+100.00%
836
P237
Min. value of PID output
ENGINEERING
–100.00%
837
P237a
Wake-up Mode
ENGINEERING
0: [Disabled]
858
P237b
Wake-up Level
ENGINEERING
0.00%
859
P238
Max. value of PID integral term
ENGINEERING
+100.00%
838
P239
Max. value of PID derivative term
ENGINEERING
+100.00%
839
P240
PID proportional constant
ENGINEERING
1.000
840
P241
Multiplicative factor of P240
ENGINEERING
0:1.0
841
P242
PID Integral time (multiples of P244)
ENGINEERING
500*Tc (ms)
842
P243
PID Derivative time (multiples of P244)
ENGINEERING
0*Tc (ms)
843
P244
Cycle time of PID regulator: Tc
ENGINEERING
5 ms
844
P245
Min. value of PID reference
ENGINEERING
0.00%
845
P246
Max. value of PID reference
ENGINEERING
+100.00%
846
P247
Min. value of PID feedback
ENGINEERING
0.00%
847
P248
Max. value of PID feedback
ENGINEERING
+100.00%
848
P249
PID reference ramp up time
ENGINEERING
0 s
849
P250
PID reference ramp down time
ENGINEERING
0 s
850
P251
Unit of measure of PID ramp
ENGINEERING
1: [0.1s]
851
P252
PID ramp start rounding off
ENGINEERING
50%
852
P253
PID ramp end rounding off
ENGINEERING
50%
853
P254
Integral term activation threshold
ENGINEERING
0.00%
854
P255
START Disable delay with PID Out=P237
ENGINEERING
0: [Disabled]
855
P256
PID output gradient limit
ENGINEERING
1 ms
856
P257
Gain for PID measure scaling
ENGINEERING
1.000
857
P260
Gain for Anti-windup
ENGINEERING
1.00
860
