Santerno Sinus Penta - List of Parameters P270 to P305

PROGRAMMING GUIDE
SINUS PENTA
203/486
26.4. List of Parameters P270 to P305
Table 56: List of parameters P270 to P305
Parameter FUNCTION User Level DEFAULT VALUES
MODBUS
Address
P270
MDO1: Digital output mode
ADVANCED
3:ANALOG
870
P271
MDO1: Selecting variable A
ADVANCED
A71: Speed
871
P272
MDO1: Selecting variable B
ADVANCED
A71: Speed
872
P273
MDO1: Testing variable A
ADVANCED
0: >
873
P274
MDO1: Testing variable B
ADVANCED
3: ≤
874
P275
MDO1: Comparing value for Test A
ADVANCED
50 rpm
875
P276
MDO1: Comparing value for Test B
ADVANCED
10 rpm
876
P277
MDO1: Function applied to the result of the 2 tests
ADVANCED
1: (A) SET (B)
RESET
877
P277a
MDO1: Selecting variable C
ADVANCED
0: Disable
642
P277b
MDO1: Function applied to the result of f(A,B) C
ADVANCED
0: f(A,B) OR C
643
P278
MDO1: Output logic level
ADVANCED
1: TRUE
878
P279
MDO2: Digital output mode
ADVANCED
6: BRAKE
879
P280
MDO2: Selecting variable A
ADVANCED
A81: Trq Output
880
P281
MDO2: Selecting variable B
ADVANCED
A71: Speed
881
P282
MDO2: Testing variable A
ADVANCED
0: >
882
P283
MDO2: Testing variable B
ADVANCED
3: ≤
883
P284
MDO2: Comparing value for Test A
ADVANCED
20%
884
P285
MDO2: Comparing value for Test B
ADVANCED
50 rpm
885
P286
MDO2: Function applied to the result of the 2 tests
ADVANCED
1: (A) SET (B)
RESET
886
P286a
MDO2: Selecting variable C
ADVANCED
0: Disable
644
P286b
MDO2: Function applied to the result of f(A,B) C
ADVANCED
0: f(A,B) OR C
645
P287
MDO2: Output logic level
ADVANCED
1: TRUE
887
P288
MDO3: Digital output mode
ADVANCED
1: DIGITAL
888
P289
MDO3: Selecting variable A
ADVANCED
D3: Inverter Alarm
889
P290
MDO3: Selecting variable B
ADVANCED
D3: Inverter Alarm
890
P291
MDO3: Testing variable A
ADVANCED
0: >
891
P292
MDO3: Testing variable B
ADVANCED
0: >
892
P293
MDO3: Comparing value for Test A
ADVANCED
0
893
P294
MDO3: Comparing value for Test B
ADVANCED
0
894
P295
MDO3: Function applied to the result of the 2 tests
ADVANCED
0: (A) OR (B)
895
P295a
MDO3: Selecting variable C
ADVANCED
0: Disable
646
P295b
MDO3: Function applied to the result of f(A,B) C
ADVANCED
0: f(A,B) OR C
647
P296
MDO3: Output logic level
ADVANCED
0: FALSE
896
P297
MDO4: Digital output mode
ADVANCED
1: DIGITAL
897
P298
MDO4: Selecting variable A
ADVANCED
D1: Inverter Run Ok
898
P299
MDO4: Selecting variable B
ADVANCED
D1: Inverter Run Ok
899
P300
MDO4: Testing variable A
ADVANCED
0: >
900
P301
MDO4: Testing variable B
ADVANCED
0: >
901
P302
MDO4: Comparing value for Test A
ADVANCED
0
902
P303
MDO4: Comparing value for Test B
ADVANCED
0
903
P304
MDO4: Function applied to the result of the 2 tests
ADVANCED
0: (A) OR (B)
904
P304a
MDO4: Selecting variable C
ADVANCED
0: Disable
648
P304b
MDO4: Function applied to the result of f(A,B) C
ADVANCED
0: f(A,B) OR C
649
P305
MDO4: Output logic level
ADVANCED
1: TRUE
905
