SINUS PENTA
PROGRAMMING GUIDE
168/486
P224 T5 Enable delay
P224
Range
0 ÷ 60000
0.0 ÷ 6000.0 sec
Default
0
0.0
Level
ENGINEERING
Address
824
Function
This parameter sets T5 enable time.
(Operation as per P216.)
P225 T5 Disable delay
P225
Range
0 ÷ 60000
0.0 ÷ 6000.0 sec
Default
0
0.0
Level
ENGINEERING
Address
825
Function
This parameter sets T5 disable time.
(Operation as per P217.)
P226 Timers Assigned to Inputs MDI1
÷
4
P226 Range
[ 0; 0; 0; 0 ] ÷ [ 5; 5; 5; 5 ]
0: No timer assigned
1 ÷ 5: T1 ÷ T5
Default
[ 0; 0; 0; 0 ]
0: No timer assigned
Level
ENGINEERING
Address
826
Function
The first group of four digital inputs may be assigned to any of the five timers and the
same timer may be assigned to multiple inputs.
Select “zero” to avoid delaying the digital inputs.
Setting via serial link: see coding table below.
Table 44: Coding of P226: Timers assigned to digital inputs MDI 1÷4
bits [15..12] bits [11..9] bits [8..6] bits [5..3] bits [2..0]
not used MDI4 MDI3 MDI2 MDI1
Coding example for P226:
MDI1=Timer T2
MDI2=No timer assigned
MDI3=Timer T2
MDI4=Timer T5
⇒ value in P226 101 010 000 010 bin = 2690 dec
P227 Timers Assigned to Inputs MDI5
÷
8
P227 Range
[ 0; 0; 0; 0 ] ÷ [ 5; 5; 5; 5 ]
0: No timer assigned
1 ÷ 5: T1 ÷ T5
Default
[ 0; 0; 0; 0 ]
0: No timer assigned
Level
ENGINEERING
Address
827
Function
The second group of four digital inputs may be assigned to any of the five timers and
the same timer may be assigned to multiple inputs.
Select “zero” to avoid delaying the digital inputs.
Setting via serial link: see coding in P226.
