PROGRAMMING GUIDE
SINUS PENTA
445/486
56. DATA LOGGER MENU
56.1. Overview
The Data Logger menu is to be used if the Penta drive cannot dialog with the Data Logger ES851 board through the
RemoteDrive software.
Parameter R116 imposes to ES851 the type of connection required for the communication mode being used.
NOTE
The Data Logger menu may be accessed only if the Data Logger board is installed and
if parameter R021 Data Logger setting is set to 2: ENABLE.
Important: The complete version of the Data Logger ES851
shall be installed (the RTC
version only is not suitable for this functionality). Please refer to the M
otor Drives
Accessories – User Manual.
NOTE
The parameters described in this menu are Rxxx parameters.
Once changed and saved, they become active only when the drive is next switched on
or when the control board is reset (by holding down the RESET key
for more than 5
secs).
CAUTION
The parameters set from this menu are not saved to non-
volatile memory of the Data
Logger board.
They must be confirmed and saved using the RemoteDrive software.
56.2. List of Parameters R115 and R116
Table 133: List of parameters R115 and R116
Parameter
FUNCTION
User Level
MODBUS Address
DEFAULT VALUES
R115
SIM Card PIN
BASIC
563
“0000”
R116
Preset connection status
ENGINEERING
134
0: no active preset
R115 SIM Card PIN
R115
Range
0x0000 ÷ 0xAAAA
“0” ÷ “9999”
Default
0x0000
“0000”
Level
BASIC
Address
563
Function
This parameter indicates the digits of the PIN of the SIM card fitted in the GSM/GPRS
modem.
The digits must be aligned left; the # symbol, which is codified as 0xA (hex) is intende
d as
the number terminator.
NOTE
Max. 4 digits are allowed for the SIM card PIN.
The PIN can be composed of less than 4 digits and the # symbol can be used as the
PIN terminator.
R116 Preset Connection Status (Line 2)
R116
Line 2
Range
0 ÷ 20
See Table 134
Address
1337
Function
This parameter indicates if preset configurations are actually set up for the types of
connections supported by ES851.
