M057 Frequency Output
M057 Range
10000÷100000
10000 ÷ 100000 Hz
Note
: The actual range depends on the min. value and the max. value of
MDO1 digital output set as a frequency reference. Values are set in P204
and P205 (see ANALOG AND FREQUENCY OUTPUTS MENU).
Active
Always active.
Address
1707
Function
This is the frequency measure produced by MDO1 digital output when set as a frequency
output.
M058 AO1 Analog Output
M058
Range
±100
±100 %
Active
Always active.
Address
1708
Function
Value percent of analog output AO1, referred to the preset max. output value (maximum
absolute value between P182 and P183, see ANALOG AND FREQUENCY OUTPUTS MENU).
M059 AO2 Analog Output
M059
Range
±100
±100 %
Active
Always active.
Address
1709
Function
Value percent of AO2 analog output referred to the preset max. output value (maximum
absolute value between P190 and P191, see ANALOG AND FREQUENCY OUTPUTS MENU).
M060 Analog Output AO3
M060
Range
±100
±100 %
Active
Always active.
Address
1710
Function
Value percent of AO3 analog output referred to the preset max. output value (maximum
absolute value between P198 and P199, see ANALOG AND FREQUENCY OUTPUTS MENU).
M061 Auxiliary Digital Outputs
M061
Range
Bit-controlled measure.
See Table 8
Active
Always active.
Address
1711
Function
Status of the auxiliary digital outputs located on the expansion board.
Table 8: Coding of Measure M061
Bit n.
Digital Output
Bit n.
Digital Output
0
XMDO1
3
XMDO4
1
XMDO2
4
XMDO5
2
XMDO3
5
XMDO6
