Table 13: List of the measures in the Power Off List
Measure Function Range Value
Modbus
Address
M090
Active Alarm
See Table 136
-
5044
M052
Supply Time
See measure
description
-
5045: LSW
5046: MSW
M054
Operation Time
See measure
description
-
5047: LSW
5048: MSW
M089
Inverter Status
See Table 139
-
5049
M026
Output Current
0 ÷ 65535
0 ÷ 6553.5 A
5050
M004
Motor Speed
±32000
±32000 rpm
5051
M002
Speed Reference after Ramps
±32000
±32000 rpm
5052
M008
Torque Demand
±32000
±32000 Nm
5053
M009
Torque Generated by the Motor
±32000
±32000 Nm
5054
M029
DC-bus Voltage
0 ÷ 1400
0 ÷ 1400 V
5055
M030
Grid Voltage
0 ÷ 1000
0 ÷ 1000 V
5056
M064
IGBT Temperature
±32000
± 320.0 °C
5057
M006
Inverter Output Frequency
±10000
±1000.0 Hz
5058
M031
Delayed Digital Inputs
See measure
description
-
5060
-
Selected Motor (high byte)
0 ÷ 2
0: Mot1
1: Mot2
2: Mot3
5061
Selected Control (low byte)
0 ÷ 2
0: IFD
1: VTC
2: FOC
M028
Output Power
0 ÷ 65535
0 ÷ 6553.5 kW
5063
M056
Digital Outputs
See measure
description
5064
M058
Analog output AO1
±100
±100 %
5065
M059
Analog output AO2
±100
±100 %
5066
M060
Analog output AO3
±100
±100 %
5067
M062
Ambient Temperature
±32000
± 320.0 °C
5068
