P80a= 2: Exclusive Preset Ref. If no Multireference is activated, the overall reference is null.
P080a Multireference Function = 2: Exclusive Preset Ref.
MDI8
MDI7
Overall Reference
0
0
0.0 bars
0
1
1.0 bars
1
0
1.5 bars
1
1
2.5 bars
15.2. List of Parameters P080a to P099a
Table 29: List of parameters P080a
÷
P099a
Parameter FUNCTION User Level DEFAULT VALUE
MODBUS
Address
P080a
PID Multireference function
ENGINEERING
0
944
P081a
PID Multireference 1 (Mref1)
ENGINEERING
0
945
P082a
PID Multireference 2 (Mref2)
ENGINEERING
0
946
P083a
PID Multireference 3 (Mref3)
ENGINEERING
0
947
P084a
PID Multireference 4 (Mref4)
ENGINEERING
0
948
P085a
PID Multireference 5 (Mref5)
ENGINEERING
0
949
P086a
PID Multireference 6 (Mref6)
ENGINEERING
0
986
P087a
PID Multireference 7 (Mref7)
ENGINEERING
0
987
P099a
PID Reference in Fire Mode
ENGINEERING
50%
988
P080a Multireference
P080a Range
0 ÷ 2
0: Preset Ref
1: Sum Ref
2: Exclusive Preset Ref.
Default
0
0: [Preset Ref]
Level
ENGINEERING
Address
944
Function
This parameter sets if the PID reference resulting from the selection of a digital
multireference is to be considered either as the unique active reference or as
summed up to the other configured PID reference sources (see example above).
P081a÷P087a PID Multireference 1÷7
P081a÷P087a
Range
–1000 ÷ +1000
±1000
Default
0
0
Level
ENGINEERING
Address
945÷949, 986÷987
Function
This is the value of the PID reference selected with the corresponding combination
of the digital inputs programmed as multireferences.
The reference is expressed in the unit of measure set with P267 (
see the
DISPLAY/KEYPAD MENU) and is based on parameter P257 (G
ain for PID
Scaling).
Example:
The max. value for the PID feedback is 100%. This value corresponds to
a level of 25m in a tank.
When P257 = 0.25, 100% of PID feedback corresponds to 25 metres.
When
setting a reference level of 15 meters, multireference 1 shall be set as P081a
=
15.0 m.
