PROGRAMMING GUIDE
SINUS PENTA
15/486
Ixxx Inputs. These are not parameters, but inputs (the values allocated to these inputs are not stored to non-volatile
memory. Ixxx value is always 0 when the drive is powered on).
Ixxx Range
Drive representation
(integer)
Display on the display/keypad and the
RemoteDrive
(may be a decimal figure)
plus unit of measure
Level
User level (BASIC / ADVANCED / ENGINEERING)
Address
Modbus address which the input can be read from/written to (integer)
Control
This optional field is displayed when a parameter is not active for all types of
motor controls (IFD / VTC / FOC)
Function Input description
NOTE
Use the ESC key to enter the value of an Ixxx input.
If the SAVE/ENTER key is used, W17 SAVE IMPOSSIBLE (warning) is displayed.
NOTE
When changing a Pxxx or Cxxx
parameter via the display/keypad, you may activate its new
value immediately (flashing cursor) or when you quit the programming mode (fixed cursor).
Typically, numeric parameters immediately come to effect, while alphanumeric parameters
have a delayed effect.
NOTE
When changing a Pxxx or Cxxx
parameter via the RemoteDrive, the drive will immediately
use the new parameter value.
0.5.4. ALARMS AND WARNINGS
The last part of this User Manual covers alarms (Axxx) and warnings (Wxxx) displayed by the drive:
Axxx
Description
Event
Possible
cause
Solution
