The type of fan control is marked by 3 characters:
Table 17: Fan control modes
Character
Description
F
The fan activation is controlled by the inverter.
S
The fan operation is correct: when a fan fault is detected, the relevant alarm trips.
N
A NTC sensor is fitted, that acquires the heatsink temperature. The fan activation threshold is set
in parameter C264.
Table 18: Coding for fan activation
Code
Symbol
Fan control
Fan status
NTC
0
---
No
No
No
1
-S-
No
Yes
No
2
F--
Yes
No
No
3
FS-
Yes
Yes
No
4
--N
No
No
Yes
5
-SN
No
Yes
Yes
6
F-N
Yes
No
Yes
7
FSN
Yes
Yes
Yes
SW Application
SW Application
Function
This screen displays the type of software application which is implemented in the
drive (e.g. Regenerative).
For the application software downloading instructions see the
Remote Drive DRIVE
REMOTE CONTROL – User Manual.
SW Versions
SW Versions
Range
0 ÷ 65535
0 ÷ 65.535
Address
Texas: 233
MMI: 1489
Motorola: 1487
Function
This screen displays the SW versions implemented on the Penta drive:
Texas
→
SW version of the DSP Texas
MMI
→
SW version of the display/keypad
Motorola → SW version of Motorola microprocessor
Maximum Output Frequency
Maximum
Output
Frequency
Range
0 ÷ 999 0 ÷ 999 Hz
Address
3327
Function
This screen displays the maximum allowable output frequency (Hz) for the drive.
NOTE
The maximum output frequency is factory-set to 599Hz for any drive models, even those
which can withstand higher output frequency values (see
Maximum Programmable Speed
Value). If the factory-set output frequency is to be increased, this is to be explicitly specified
when ordering the equipment.
