22. ANALOG AND FREQUENCY OUTPUTS MENU
22.1. Overview
NOTE
Please refer to the Sinus Penta’s Installation Guide
for the hardware description of the
analog output and the frequency output or for the configuration of the dip-
switches for
voltage/current outputs.
NOTE
MDO1 digital output is used when the frequency output is enabled (P200
other than
Disabled). Any configuration set in the DIGITAL OUTPUTS MENU will have no effect.
The Sinus Penta drive allows configuring three programmable analog outputs as voltage outputs or current outputs, as
well as one frequency output.
22.1.1. FACTORY-SETTING OF THE ANALOG OUTPUTS
Analog outputs are factory set to voltage values ranging from ± 10V and the following variables are selected:
TERMINALS OUTPUTS SELECTED VARIABLE
OUTPUT
RANGE
MIN.
VALUE
MAX.
VALUE
10
AO1
Speed (speed of the connected motor)
±10V
-1500
1500
11 AO2
Speed Ref. (speed reference at constant
rpm)
±10V
-1500 1500
12
AO3
Current of the connected motor
±10V
0
Imax *
* Depending on the inverter size.
22.1.2. ANALOG OUTPUTS
As per the analog outputs, the ANALOG AND FREQUENCY OUTPUTS MENU allows selecting the variable to be
represented, its range, its acquisition mode (± or as an absolute value), the type of analog output (voltage/current) and
the output values corresponding to the min. value and the max. value of the selected variable. An offset value and a
filtering function may also be applied to the analog outputs. For the frequency output, this menu contains the parameters
for the selection of the represented variable, its acquisition mode (± or as an absolute value), its min. value and max.
value and the corresponding output frequency value, and a filtering function. The figure below shows the typical
structure of the analog outputs; in particular, AO1analog output and its parameter set are illustrated.
