Santerno Sinus Penta - List of Parameters C215 to C224

PROGRAMMING GUIDE
SINUS PENTA
369/486
40.2. List of Parameters C215 to C224
Table 114: List of parameters C215 to C224
Parameter FUNCTION User Level
MODBUS
Address
Default
Values
C215
Enabling DCB at Stop Function
ADVANCED
1215
0:NO
C216
Enabling DCB at Start Function
ADVANCED
1216
0:NO
C217
DCB at Stop Duration
ADVANCED
1217
0.5
C218
DCB at Start Duration
ADVANCED
1218
0.5
C219
Speed at the Beginning of DCB at Stop
ADVANCED
1219
50rpm
C219a
VTC Speed Ramp Duration
ENGINEERING
1213
500 ms
C220
DCB Current Level
ADVANCED
1220
100%
C220a
VTC Current Filter Time Constant
ENGINEERING
1214
300 ms
C220b
Proportional Gain of the VTC Current
Controller
ENGINEERING 1236 20
C220c
Integral Time Constant of the VTC Current
Regulator
ENGINEERING 1237 100 ms
C221
DCB Hold
ADVANCED
1221
0%
C222
Ramp Braking Time for Motor 1 DCB
ENGINEERING
1222
See Table 82
and Table 86
C223
Ramp Braking Time for Motor 2 DCB
ENGINEERING
1223
C224
Ramp Braking Time for Motor 3 DCB
ENGINEERING
1224
C215 Enabling DCB at Stop Function
C215
Range
0 ÷ 1
0: No; 1: Yes
Default
0
0: No
Level
ADVANCED
Address
1215
Control
IFD and VTC
Function
Enables DC Braking during deceleration when the speed set in C219 is
reached (or the speed set in C235 if in Power Down mode and C234
[DCB] is
reached).
C216 Enabling DCB at Start Function
C216
Range
0 ÷ 1
0: No; : Yes
Default
0
0: No
Level
ADVANCED
Address
1216
Control
IFD and VTC
Function
Enables the DC Braking at Start function.
C217 DCB at Stop Duration
C217
Range
1 ÷ 600
0.1; 60.0 sec.
Default
5
0.5 sec
Level
ADVANCED
Address
1217
Control
IFD and VTC
Function
Determines the duration of the DCB at Stop function (C215=1:Yes or C160
enabled).
