Santerno Sinus Penta - Table 15: Indexes Corresponding to the Different Models (Sizes) of the Penta Drive

PROGRAMMING GUIDE
SINUS PENTA
79/486
Product Name and Type
Product Name
and Type
Range
Fan control: bits 0 to 3
Voltage class: bits 4 to 7
Drive size: bits 8 to 15
0 ÷ 7 – see Table 18
0 ÷ 3 – see Table 16
0 ÷ 96 – see Table 15
Address
Type: 1593
Function
This screen displays the name
of the product (PENTA) and the type of product (see
example below).
P
r
o
d
u
c
t
N
a
m
e
P
E
N
T
A
T
y
p
e
0
0
2
0
4
T
–
–
–
The product name (PENTA) appears in the second line of the display/keypad. The third line shows the voltage class, the
size of the drive and the type of fan control.
In the case shown in the example, the voltage class is 4T (400V), the size of the drive is 0020 and the fan operation is
not controlled by the drive (character _ ).
The numbers corresponding to the different models of the Penta Drive are given in the table below:
Table 15: Indexes corresponding to the different models (sizes) of the Penta Drive
Index
Model
Index
Model
Index
Model
Index
Model
Index
Model
0
0003
20
0023
40
0076
60
0259
80
0748
1
0004
21
0024
41
0086
61
0260
81
0749
2
0005
22
0025
42
0088
62
0290
82
0750
3
0006
23
0030
43
0113
63
0312
83
---
4
0007
24
0032
44
0129
64
0313
84
0828
5
0008
25
0033
45
0131
65
0314
85
0831
6
0009
26
0034
46
0150
66
0366
86
0832
7
0010
27
0035
47
0162
67
0367
87
0850
8
0011
28
0036
48
0164
68
0368
88
0960
9
0012
29
0037
49
---
69
0399
89
0964
10
0013
30
0038
50
0179
70
0401
90
0965
11
0014
31
0040
51
0180
71
0402
91
1128
12
0015
32
0042
52
0181
72
0457
92
1129
13
0016
33
0049
53
0200
73
0459
93
1130
14
0017
34
0051
54
0201
74
0523
94
1296
15
0018
35
0060
55
0202
75
0524
95
1800
16
0019
36
0062
56
0216
76
0526
96
2076
17
0020
37
0067
57
0217
77
0598
97
---
18
0021
38
0069
58
0218
78
0599
98
---
19
0022
39
0074
59
0250
79
0600
99
---
Table 16: Voltage classes of the PD
Index
Class
0
2T
1
4T
2
5T
3
6T
