1. USING THE DISPLAY/KEYPAD UNIT
1.1. Overview
This section contains several examples about navigating in the display/keypad unit and the UPLOAD and DOWNLOAD
functions of the programming settings of the drive when using the keypad.
More details about the keypad settings (contrast, backlight, etc.) are given in the section covering the display/keypad in
the Installation Guide. Details about custom navigation in the root page, the measures in the Keypad page and the Root
page and the custom unit of measure of the PID controller are given in the DISPLAY/KEYPAD MENU in this manual.
When using the navigation “by menu” mode (P264 = BY MENU), the structure of the menu tree that can be explored
using the display/keypad is described in the Menu Tree section.
The complete tree structure is displayed, but the actual structure depends on the user level set in P001 and on the
implemented programming. For example, if only motor 1 is programmed (C009=1), the menus relating to motors 2 and 3
will not be displayed (Motor 2/3 Configuration and Motor 2/3 Limit). Also, if the type of motor control is C010=IFD
Voltage/Freq., the BRIDGE CRANE MENU will not be displayed.
When P264 = Linear (linear navigation), the parameters displayed are no longer grouped into menus, and you can scroll
through all parameters using the ▲ and ▼ keys.
When P264 = Modified Pars. Only, only the parameters having different values than the factory settings are displayed,
and you can scroll through all parameters using the ▲ and ▼ keys.
The Navigation section shows how to use function keys to navigate through the parameters and to change parameter
values (P264 = BY MENU).
The function keys and their functionality are described below.
