PROGRAMMING GUIDE

SINUS PENTA

325/486

37.2. Factory-setting of the Digital Inputs

Table 97: Terminal board: Factory-setting

Function

Terminal

Description

START

14: MDI1

Enables the drive RUN

ENABLE

15: MDI2&S

Enables the drive

RESET

16: MDI3

Resets the alarms tripped

MULTISPEED 0

17: MDI4

Bit 0 for Multispeed selection

MULTISPEED 1

18: MDI5

Bit 1 for Multispeed selection

Source Sel

19: MDI6

Source Selection

Loc/Rem

20: MDI7

Local / Remote Control Selection

CW/CCW

21: MDI8

Reference reversal
