Santerno Sinus Penta - List of Parameters P390 to P399

PROGRAMMING GUIDE
SINUS PENTA
251/486
Parameter P396 is the X-axis of the first point; parameter P397 is the X-axis of the second point.
(see also Scaling Analog Inputs REF, AIN1, AIN2).
31.2. List of parameters P390 to P399
Table 67: List of parameters P390 to P399
Parameter FUNCTION User Level
DEFAULT
VALUE
MODBUS
Address
P390
Type of signal over XAIN4 input
ADVANCED
1:0÷10V
990
P391
Value of XAIN4 input producing min. reference (X-
axis)
ADVANCED 0.0V 991
P391a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P391)
ADVANCED 100.0% 704
P392
Value of XAIN4 input producing max. reference (X-
axis)
ADVANCED 10.0V 992
P392a
Percentage of Speed_Max/Trq_Max producing max.
reference (Y-axis related to P392)
ADVANCED 100.0% 710
P393
Offset over XAIN4 input
ADVANCED
0V
993
P394
Filtering time over XAIN4 input
ADVANCED
100ms
994
P395
Type of signal over XAIN5 input
ADVANCED
3: 4÷20mA
995
P396
Value of XAIN5 input producing min. reference (X-
axis)
ADVANCED 4.0mA 996
P396a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P396)
ADVANCED 100.0% 711
P397
Value of XAIN5 input producing max. reference (X-
axis)
ADVANCED 20.0mA 997
P397a
Percentage of Speed_Min/Trq_Min producing min.
reference (Y-axis related to P397)
ADVANCED 100.0% 712
P398
Offset over XAIN5 input
ADVANCED
0mA
998
P399
Filtering time over XAIN5 input
ADVANCED
100 ms
999
P390 Type of Signal over XAIN4 Input
P390 Range
0 ÷ 1
0: ± 10 V
1: 0 ÷ 10 V
Default
1
1:0÷10V
Level
ADVANCED
Address
990
Function
This parameter selects the type of single–ended, analog signal over XAIN4
terminal in the terminal board. The s
ignal can be a voltage signal, a unipolar
signal, or a bipolar signal.
0: ± 10 V Bipolar voltage input between –10V and +10V. The detected signal is
saturated between these two values.
1: 0 ÷ 10 V Unipolar voltage input between 0V and +10V. The detected s
ignal is
saturated between these two values.
