SINUS PENTA
PROGRAMMING GUIDE
68/486
8.8. Autodiagnostics Menu
This menu allows the user to check the functioning times and the relevant counters (for maintenance purposes) of the
Penta drive; it also allows reading out the analog channels used for temperature sensors and the relevant temperature
values, as well as the drive status.
M052 / M054 Functioning Times
M052 /
M054
Range
0 ÷ 2147483647 (0 ÷ 7FFFFFFFh) 0 ÷429496729.4 sec
Address
Supply Time: 1702-1703 (LSWord, MSWord)
Operation Time: 1704-1705 (LSWord, MSWord)
Function
This screen displays the ST (supply time) and the OT (operation time).
The Operation Time is the activation time of the drive IGBTs.
Both values are expressed in 32 bits divided into two 16-
bit words: the low part and the high
part.
Functioning Times:
S
u
p
p
l
y
T
i
m
e
M
0
5
4
=
5
3
:
2
5
:
0
1
O
p
e
r
a
t
i
o
n
T
i
m
e
M
0
5
2
=
2
9
:
3
5
:
5
1
M062 Ambient temperature Measure
M062
Range
± 32000
± 320.0 °C
Active
Always active.
Address
1712
Function
Ambient temperature measured on the surface of the control board.
M064 IGBT Temperature Measure
M064
Range
± 32000
± 320.0 °C
Active
Always active.
Address
1714
Function
Measure of the IGBT temperature.
If the temperature readout is <–30.0 °C or >150.0 °C, warning W50 NTC Fault appears.
Note: Not all models are provided with the NTC sensor (see Table 17 in the PRODUCT MENU).
If this sensor is not provided, the measure is forced to 32,000, corresponding to +320.0 °C.
