8.11. Digital Input Settings Menu
This menu allows checking the functions assigned to the digital inputs.
Table 10: Coding of the functions assigned to the digital inputs
Displayed Items
Function Assigned to the Digital Inputs
STOP
Stop function
REVERSE
Startup with negative speed
EN-SW
ENABLE SW
DISABLE
Drive disable
Mspd0
Multispeed 0
Mspd1
Multispeed 1
Mspd2
Multispeed 2
Mspd3
Multispeed 3
CW/CCW
Reversal of the direction of rotation
DCB
DC braking
UP
Reference increase
DOWN
Reference decrease
UDReset
Reset of speed setpoint due to UP/DOWN command
Alarm 1
Auxiliary trip 1
Alarm 2
Auxiliary trip 2
Alarm 3
Auxiliary trip 3
MRmp0
Multiramp 0
MRmp1
Multiramp 1
JOG
Jog mode
SLAVE
Selection of Slave Mode
PID Dis
PID Disable
KpdLock
Display/keypad unit
Mot 2
Selection of Motor 2
Mot 3
Selection of Motor 3
Var 0
Reference Variation 0
Var 1
Reference Variation 1
Var 2
Reference Variation 2
PID UDR
PID Reference Reset due to UP/DOWN commands
LOCAL
Selection of Local mode
Brk Lock
Mechanical brake locking
FireM
Fire Mode enabled
Src. Sel
Reference/command source switch
nTlim
External torque limit disable
START_B
START function, terminals B
STOP_B
STOP function, terminals B
REVERSE_B
Startup with negative speed, terminals B
MRef0
PID Multireference 1
MRef1
PID Multireference 2
MRef2
PID Multireference 3
PID Csl
PID Control Selection
START
START function
ENABLE
ENABLE function
RESET
Alarm RESET
EncA
Encoder A Input
EncB
Encoder B Input
FinA
FINA Frequency input
FinB
FINB Frequency input
Multi
More than one function allocated to the same input
