SINUS PENTA

PROGRAMMING GUIDE

132/486

17.2. List of Parameters P105 to P108

Table 31: List of parameters P105 to P108

Parameter FUNCTION User Level

MODBUS

Address

P105

Prohibit speed 1

ADVANCED

705

P106

Prohibit speed 2

ADVANCED

706

P107

Prohibit speed 3

ADVANCED

707

P108

Hysteresis (band) of prohibit speed ranges

ADVANCED

708

P105 (P106, P107) Prohibit Speed 1 (2, 3)

P105

Range

0 ÷ 32000

0 ÷ 32000 rpm

Default

0 rpm

Level

ADVANCED

Address

705

706

707

Function

Determines the intermediate value of the first prohibit speed range. This value is to

be considered as an absolute value, i.e. independent of the speed reference sign

(+/-).

P108 Hysteresis (band) of Prohibit Speed Ranges

P108

Range

0 ÷ 5000

0 ÷ 5000 rpm

Default

0 rpm

Level

ADVANCED

Address

708

Function

Sets the semi-amplitude of the prohibit speed ranges.
