PROGRAMMING GUIDE
SINUS PENTA
91/486
Table 22: List of the programmable measurements for P268, P268a, P268b, P268c, P268d, P268e
M000 Speed Ref
M043 dcm.Fbus.SpdRef
M001 dcm.Spd.Ref
M044 Ser.TrqLimRef
M002 Ramp Out
M045 Fbus.TrqLimRef
M003 dcm.Rmp.Out
M046 SerPID Ref
M004 Motor Speed
M047 FbusPID Ref
M005 dcm.Mot.Spd
M048 SerPID Fbk
M006 Mot.Freq.
M049 FbusPID Fbk
M007 Torq.Ref
M050 Encoder Ref
M008 Torq.Demand
M051 Freq.In Ref
M009 Torq.Out
M056 Digital Out
M010 Torq.Ref %
M057 Freq.Out
M011 Torq.Dem.%
M058 Analog Out AO1
M012 Torq.Out %
M059 Analog Out AO2
M013 T.Lim.Ref
M060 Analog Out AO3
M014 T.Lim.RmpOut
M061 Aux. Dig.OUT
M015 T.Lim.Ref %
M062 Amb.Temp.
M016 T.Lim.RmpOut %
M036a Aux.Ser. Dig.IN
M017 Flux Ref
M064 Hts.Temp.
M018 PID Ref %
M065 OP Counter
M019 PID RmpOut %
M066 SP Counter
M020 PID Fbk %
M036b Aux.FBus. Dig.IN
M021 PID Err %
M022a PID2 Out %
M022 PID Out %
M069 PT100 Temp.1
M023 PID Ref
M070 PT100 Temp.2
M024 PID Fbk
M071 PT100 Temp.3
M056a Virtual Dig.Out
M072 PT100 Temp.4
M026 Mot.Current
M028a Energy (low)
M027 Out Volt
M028a Energy (high)
M028 Power Out
M013a Speed Lim Ref
M029 Vbus-DC
M014a Speed Lim Out
M030 V Mains
M026a I2t
M031 Delay.Dig.IN
M039a Analog In XAIN4
M032 Istant.Dig.IN
M039b Analog In XAIN5
M033 Term. Dig.IN
M018a PID2 Ref %
M034 Ser. Dig.IN
M019a PID2 RmpOut %
M035 Fbus. Dig.IN
M020a PID2 Fbk %
M036 Aux. Dig.IN
M021a PID2 Err %
M037 Analog In REF
M023a PID2 Ref
M038 Analog In AIN1
M024a PID2 Fbk
M039 Analog In AIN2
M089 Status
M040 Ser.SpdRef
M090 Alarm
M041 dcm.Ser.SpdRef
M056b Timed Flags TFL
M042 Fbus.SpdRef
M027a Power Factor
