SINUS PENTA
PROGRAMMING GUIDE
90/486
P268 (P268a) Measure n.1 (n.2) on Root Page
P268 / P268a
Range
M000 ÷ M027a (see Table 23)
Default
P268 → M004 Motor Spd
P268a
→
M000 Speed Ref.
Level
ADVANCED
Address
Cannot be accessed via serial link.
Function
These two parameters allow selecting two measures to be displayed on the Root
Page.
P268y (P268z) Scaling of Measure n.1 (n.2) on Root Page
P268y / P268z
Range
0 ÷ 10000
0 ÷ 100.00%
Default
10000
100.00%
Level
ADVANCED
Address
515 / 516
Function
These parameters allow scaling the read-out of the measures on the Root page
which have been selected with parameters P268 and P268a.
P268b (P268c, P268d, P268e) Measure n.1 (n.2, n.3, n.4) on Keypad Page
P268b, P268c,
P268d, P268e
Range
M000 ÷ M027a (see Table 23)
Default
P268b → M006 Mot.Freq.
P268c → M026 Motor Current
P268d → M004 Motor Spd
P268e → M000 Speed Ref.
Level
ADVANCED
Address
Cannot be accessed via serial link.
Function
These four parameters allow selecting four measures to be displayed on the
Keypad Page.
NOTE
Measure n. 4 is available in the measure Keypad page only. The reference to measure
n. 4 is available for the remaining Keypad pages.
