Santerno Sinus Penta - List of Parameters P436 to P460

SINUS PENTA
PROGRAMMING GUIDE
186/486
25.2. List of Parameters P436 to P460
Table 46: List of parameters P436 to P460
Parameter FUNCTION User Level
DEFAULT
VALUES
MODBUS
Address
P436
Max. value of PID2 output
ENGINEERING
+100.00%
1346
P437
Min. value of PID2 output
ENGINEERING
–100.00%
1347
P437a
Wake-up Mode
ENGINEERING
0: [Disabled]
1282
P437b
Wake-up Level
ENGINEERING
0.00%
1283
P438
Max. value of PID2 integral term
ENGINEERING
+100.00%
1348
P439
Max. value of PID2 derivative term
ENGINEERING
+100.00%
1349
P440
PID2 proportional constant
ENGINEERING
1.000
1350
P441
Multiplicative factor of P440
ENGINEERING
0:1.0
1351
P442
PID2 Integral time (multiples of P444)
ENGINEERING
500*Tc (ms)
1352
P443
PID2 Derivative time (multiples of P444)
ENGINEERING
0*Tc (ms)
1353
P444
Cycle time of PID2 regulator: Tc
ENGINEERING
5 ms
1354
P445
Min. allowable value of PID2 reference
ENGINEERING
0.00%
1355
P446
Max. allowable value of PID2 reference
ENGINEERING
+100.00%
1356
P447
Min. allowable value of PID2 feedback
ENGINEERING
0.00%
1357
P448
Max. allowable value of PID2 feedback
ENGINEERING
+100.00%
1358
P449
PID2 reference ramp up time
ENGINEERING
0 s
1359
P450
PID2 reference ramp down time
ENGINEERING
0 s
1360
P451
Unit of measure of PID2 ramp
ENGINEERING
1: [0.1s]
1361
P452
PID2 ramp start rounding off
ENGINEERING
50%
1362
P453
PID2 ramp end rounding off
ENGINEERING
50%
1363
P454
Integral term activation threshold
ENGINEERING
0.00%
1364
P455
START Disable delay with PID Out=P437
ENGINEERING
0: [Disabled]
1284
P456
PID2 output gradient limit
ENGINEERING
1 ms
1368
P457
Gain for PID2 measure scaling
ENGINEERING
1.000
1369
P460
Gain for Anti Wind-Up
ENGINEERING
1.00
1370
NOTE
Parameters P437a, P437b and P455 are overridden if the
Two PIDs mode is selected with
“summed outputs” (C291a = 7: 2 PID and C171a = 0: Disabled).
