Santerno Sinus Penta - Table 129: Word for Address 230

PROGRAMMING GUIDE
SINUS PENTA
431/486
R018a Fieldbus Baud Rate
R018a Range
0÷3
0 → 125k
1 → 250k
2 → 500k
3 → Autodetect
Default
0
0 → 125k
Level
ENGINEERING
Validity
Boards: B40
DeviceNet
Address
230 bit 8-11
Function
This is the slave baud rate in bps.
It is active only for DeviceNet fieldbus with B40 boards.
R018b Type of WatchDog
R018b Range
0÷2
0 → bit 15 at 1
1 → bit 15 in toggle
2 → with B40 state
Default
0
0 → bit 15 at 1
Level
ENGINEERING
Address
230 bits 12-15
Validity
Boards: B40
Function
Indicates the type of active WatchDog:
0  after having established a connection to the Master device for the
first time,
if R016 > 0, the system checks if bit 15 of word 5 (digital inputs from Fieldbus)
is
set to 1. If the bit drops to zero for a time longer than R016, alarm A070
Fieldbus
WDG trips.
1  After having established a connection to the Master device
for the first time,
if R016 > 0, the system checks if bit 15
of word 5 (digital inputs from Fieldbus)
continuously changes 0-1. If the bit is kept at one of the
two values for a time
longer than R016, A070 alarm A070 Fieldbus WDG trips.
2  After having established a connection to the Master device for the first time
,
if R016 > 0, the system checks if the status of B40
board is kept in Connect
status. If the Disconnect status is kept for a time longer than R016, A070
alarm
A070 Fieldbus WDG trips.
It is active only for B40 boards.
Table 129: Word for address 230
bit [15..12] bit [11..8] bit [7..0]
R018b R018a R018
