Santerno Sinus Penta - List of Parameters P216 to P229

SINUS PENTA
PROGRAMMING GUIDE
166/486
23.2. List of Parameters P216 to P229
Table 43: List of parameters P216 to P229
Parameter FUNCTION User Level Default Values
MODBUS
Address
P216
T1 Enable delay
ENGINEERING
0.0
816
P217
T1 Disable delay
ENGINEERING
0.0
817
P218
T2 Enable delay
ENGINEERING
0.0
818
P219
T2 Disable delay
ENGINEERING
0.0
819
P220
T3 Enable delay
ENGINEERING
0.0
820
P221
T3 Disable delay
ENGINEERING
0.0
821
P222
T4 Enable delay
ENGINEERING
0.0
822
P223
T4 Disable delay
ENGINEERING
0.0
823
P224
T5 Enable delay
ENGINEERING
0.0
824
P225
T5 Disable delay
ENGINEERING
0.0
825
P226
Timer assigned to inputs MDI1÷4
ENGINEERING
0: No timer assigned
826
P227
Timer assigned to inputs MDI5
÷
8
ENGINEERING
0: No timer assigned
827
P228
Timer assigned to outputs MDO1÷4
ENGINEERING
0: No timer assigned
828
P229
Timer assigned to virtual outputs
MPL1÷4
ENGINEERING 0: No timer assigned 829
P216 T1 Enable delay
P216
Range
0 ÷ 60000
0.0 ÷ 6000.0 sec
Default
0
0.0
Level
ENGINEERING
Address
816
Function
This parameter sets T1 enable time.
Using P226 or P227, if timer T1
is assigned to a digital input having a
particular function, P216 represents the delay occu
rring between the input
closure and the function activation.
Use P228 to assign timer 1 to a digital output; in that case, the digital output
energizing will be delayed according to the time set in P216.
P217 T1 Disable delay
P217
Range
0 ÷ 60000
0.0 ÷ 6000.0 sec
Default
0
0.0
Level
ENGINEERING
Address
817
Function
This parameter sets T1 disabling time.
Using P226 or P227, if timer T1
is assigned to a digital input having a
particular function, this parameter represents the delay occurring b
etween the
input opening and the function deactivation.
Use P228 to assign timer 1 to a digital output; in that case, the digital output
de-energizing will be delayed according to the time set in P217.
